Integrated amplifiers — Arcam A5
Description, images, technical data and specifications
Arcam A5
Image source — © Arcam
Specifications
Model name
A5
Type
integrated amplifier with DAC
Analog inputs (balanced)
0
Analog inputs (single-ended)
3 + 1 (phono)
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
47000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
2 x 50
Output power (4Ω) (W)
2 x 75
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20000
Signal to Noise Ratio (dB)
106
Total Harmonic Distortion + Noise (%)
N/A
Damping factor
N/A
Dimensions (mm)
431 x 344 x 83
Weight (kg)
8.14
Official link
