Integrated amplifiers — Cayin MT-35 MK3
Description, images, technical data and specifications
Cayin MT-35 MK3
Image source — © Cayin
The Cayin MT-35 Mk3 vacuum tube integrated amplifier operates in class A/B and offers 2 x 36 W of output power in ultra-linear mode. The output stages are built on four EL34 pentodes (two per channel), while the pre-amplification stages employ dual 12AX7 (or ECC83) and 12AU7 (or ECC82) triodes.
Specifications
Model name
MT-35 MK3
Type
integrated amplifier with Bluetooth DAC ES9018K2M Sabre32
Analog inputs (balanced)
0
Analog inputs (single-ended)
3
Input sensitivity (mV)
300
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
100000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
N/A
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
2 x 36
Output power (4Ω) (W)
2 x 36
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
8
Frequency response high +/- 3dB (Hz)
60000
Signal to Noise Ratio (dB)
93
Total Harmonic Distortion + Noise (%)
0,25
Damping factor
N/A
Dimensions (mm)
326 × 278 × 184
Weight (kg)
13.5
Official link
