Power amplifiers stereo — PrimaLuna EVO 100-4
Description, images, technical data and specifications
PrimaLuna EVO 100-4
Image source — © PrimaLuna
Specifications
Model name
EVO 100-4
Input sensitivity (mV)
880
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
100 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
40 / 45 (stereo)
Output power (4Ω) (W)
N/A
Gain (dBu)
28
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
95 000
Signal to Noise Ratio (dB)
92
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.2
Max power consumption (W)
280
Damping factor
N/A
Dimensions (mm)
405 x 280 x 190
Weight (kg)
17
Official link
