Power amplifiers stereo — CH Precision M10 Stereo
Description, images, technical data and specifications
CH Precision M10 Stereo
Image source — © CH Precision
Doubled the power supply capacity (vs. M.1.1) High End amp offers bandwidth up to 500kHz and delivers 2 x 550 Wt (4 Ohms load)!
Specifications
Model name
M10 Stereo
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
94000 - 600
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
2 x 900
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
2 x 300
Output power (4Ω) (W)
2 x 550
Gain (dBu)
N/A
Sensitivity (mV)
N/A
Frequency response low +/- 3dB (Hz)
0
Frequency response high +/- 3dB (Hz)
500000
Signal to Noise Ratio (dB)
132
Total Harmonic Distortion + Noise (0% global feedback) (%)
0.01
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.002
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
N/A
Weight (kg)
78 + 53
