Bookshelf Speakers — JBL 4305P

Description, images, technical data and specifications

JBL 4305P
Image source — © JBL

Inside, there is a 5.25-inch woofer with a composite fiber diffuser and a molded frame and a 2410H-2 inch compression driver with a High-Definition Imaging horn. The bass player works in a configuration with a bass reflex. The drivers are complemented by a Class D amplifier, which provides 25 watts for each compression driver and 125 watts for the low frequency.

Specifications

  • Model name

    4305P

  • Frequency Response low +/- 3dB (Hz)

    45

  • Frequency Response high +/- 3dB (Hz)

    25 000

  • Sensitivity (dB at 1 W/1m)

    N/A

  • Impedance (Ohms)

    N/A

  • Power amplifier requirements (W)

    N/A

  • Has internal amplification

    Yes

  • Internal amplification power (W)

    150

  • Size (sm)

    59.7 x 29.0 x 45.8

  • Weight (kg)

    16.6

  • Official link

    https://www.jbl.com/loudspeakers/4305P-.html
