Westlake Reference SM-1
Image source — © Westlake

The Westlake Reference SM-1 speaker systems are a five—column model. Two 18-inch drivers with paper diffusers on a rigid suspension are responsible for the bass, and a 12—inch driver of a similar design is responsible for the midbass. This is followed by compression two- and one-inch horn drivers, and the high-frequency half-inch driver completes everything.

Specifications

  • Model name

    Reference SM-1

  • Frequency Response low +/- 3dB (Hz)

    20

  • Frequency Response high +/- 3dB (Hz)

    20 000

  • Sensitivity (dB at 1 W/1m)

    101

  • Impedance (Ohms)

    4

  • Power amplifier requirements (W)

    600 - 1800

  • Has internal amplification

    N/A

  • Internal amplification power (W)

    N/A

  • Size (sm)

    99 x 124.5 x 81.3

  • Weight (kg)

    158.8

  • Official link

    https://www.westlakeaudio.com/
