DACs — Weiss Engineering DAC502
Description, images, technical data and specifications
Weiss Engineering DAC502
Image source — © Weiss Engineering
The device uses a pair of 32-bit ESS Sabre chips and an analog power supply of excess power with dedicated stabilizers for each part of the circuit. The network switch is implemented on an electronic relay, there are two network transformers, separately for each channel. The device accepts signals up to PCM 32/384, DSD128 and clearly shows what the power and strength of High End sound is.
Specifications
Model name
Weiss DAC502
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to PCM 32/384 and DSD128
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20000
Gain (dBu)
N/A
Output Level (balanced) (V)
7.957 (selectable)
Output Level (single-ended) (V)
3.98 (selectable)
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (% at 22 kHz)
0.00014
Dimensions (mm)
45 x 30 x 6.6
Weight (kg)
5
Official link
