DACs — Musical Fidelity M8x DAC
Description, images, technical data and specifications
Musical Fidelity M8x DAC
Image source — © Musical Fidelity
The M8x DAC from Musical Fidelity is based on two Sabre ES9038Q2M chips from ESS Technologies, operating in a fully balanced, dual differential configuration. The DAC is capable of decoding digital streams in PCM format with parameters up to 32 bit / 768 kHz and native DSD up to DSD512 (the maximum resolution is available when using the USB interface).
Specifications
Model name
M8x DAC
Conversion type
N/A
Engine
2 x Sabre ES9038Q2M
DSD compatability
Yes
Parameters
up to PCM 32/768 and DSD512
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
20000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
100
Output Impedance (single-ended) (Ω)
100
Analog outputs
N/A
Signal to Noise Ratio (dB)
100
Total Harmonic Distortion + Noise (% at 22 kHz)
0,001
Dimensions (mm)
483 x 102 x 381
Weight (kg)
10.6
