Streamers — McIntosh DS200 Streaming DAC
Description, images, technical data and specifications
McIntosh DS200 Streaming DAC
Image source — © McIntosh
The model offers Spotify Connect and TIDAL Connect options along with Apple AirPlay, Roon Ready, Bluetooth 5.0 (AAC, and Qualcomm aptX HD), and Google Cast (Google Assistant compatible for voice control is also on board) – so you won’t need any additional apps to control the device.
Specifications
Model name
DS200 Streaming DAC
Has internal DAC
Yes
DSD compatability
Yes
Parameters
up to PCM 32/384 and DSD512
DSP processing
N/A
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
60000
Gain (dBu)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
100
Output Impedance (single-ended) (Ω)
100
Analog outputs level (balanced) (V)
4 (0 - 16)
Analog outputs level (single-ended) (V)
2 (0 - 8.0)
Signal to Noise Ratio (dB)
100
Total Harmonic Distortion + Noise (% at 22 kHz)
0.005
Dimensions (mm)
445 x 152 x 432
Weight (kg)
12.5
Official link
