Cartidges — Clearaudio Titanium V2
Description, images, technical data and specifications
Clearaudio Titanium V2
Image source — © Clearaudio
The newest Clearaudio Titanium V2 cartridge, although it occupies the second line from the top in the company's model range, but, in fact, accumulates all the proprietary technologies. Eight neodymium magnets installed in the ring create a magnetic field of such strength that the channel separation of the cartridge exceeds a record 40 dB. The coils are wound with gold, the cantilever is made of ora, and the diamond needle has a Micro HD sharpening.
Specifications
Model name
Titanium V2
Type
MC
Stylus
diamond
Body
titanium
Cantilever
boron Clearaudio Prime Line
Coils
24 carat gold
Output voltage (mV@5cm/sec)
0.5
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20000
Internal impedance (Ohm)
50
Channel separation (dB / 1,000 Hz)
30
Compliance (×10-6cm/dyne at 100Hz)
15
Recommended load (Ohm)
N/A
Recommended tonearms
Medium
Weight (g)
10
