Phonostages — Audio Research PH9

Description, images, technical data and specifications

Audio Research PH9
Image source — © Audio Research

The PH9 phono corrector is an excellent solution for matching most cartridge and player combinations to your system. The 6H30 vacuum tube trio is at the heart of a simple and clear signal path to ensure the most transparent pre-amplification.

Specifications

  • Model name

    PH9

  • Inputs (balanced)

    N/A

  • Inputs (single-ended)

    1

  • MC current-sensing input impedance (Ω)

    47 000

  • MM/MC voltage input impedance (Ω)

    N/A

  • Output impedance (Ω)

    200

  • Gain (dB)

    58

  • Playback EQ curves accuracy (dB)

    N/A

  • Frequency response low +/- 3dB (Hz)

    0.3

  • Frequency response high +/- 3dB (Hz)

    80 000

  • Total Harmonic Distortion + Noise (%)

    <0.015%

  • Dimensions (mm)

    480 × 137 × 348

  • Weight (kg)

    7

  • Official link

    https://audioresearch.com/new_website/audio-research-ph9-phono-stage/
