Aune S17 Pro EVO – Class A Headphone Amplifier
30.12.2024 09:20 | ~1 minute read
Aune has introduced a new headphone amplifier, the Aune S17 Pro EVO. The model is suitable for headphones with a nominal impedance of 32 to 600 Ohms and is equipped with balanced outputs.
The output stage of the Aune S17 Pro EVO uses two pairs of transistors connected in parallel in each channel, which makes up a total of 16 output elements. The volume control is implemented on an R2R matrix, which provides precise control of the signal level.
The cooling system with internal radiators and a massive metal plate effectively dissipates heat, maintaining stable Class A amplification. The power supply of the device is equipped with a 50 W toroidal power transformer and capacitors in the filter with a total capacity of 19,200 μF. The Aune S17 Pro EVO headphone amplifier delivers 7.5W of output power when driving headphones with a nominal impedance of 32 ohms.
Aune S17 Pro EVO power into 6.35 mm (Low Gain): 32 ohms – 738 mW, 100 ohms – 266 mW, 150 ohms – 177 mW, 200 ohms – 133 mW, 250 ohms – 106 mW, 300 Ohms – 88 mW, 470 Ohms – 56 mW, 600 Ohms – 44 mW. 4-Pin XLR Output Power (Low Gain): 32 Ohms – 2880 mW, 55 Ohms – 1764 mW, 90 Ohms – 765 mW, 100 Ohms – 1000 mW, 150 Ohms – 694 mW, 200 Ohms – 520 mW, 250 Ohms – 416 mW, 300 Ohms – 347 mW, 470 Ohms – 221 mW, 600 Ohms – 173 mW. 6.35 mm Output Power (High Gain): 32 Ohms – 2050 mW, 100 Ohms - 688 mW, 150 Ohms - 464 mW, 200 Ohms - 348 mW, 250 Ohms - 282 mW, 300 Ohms - 235 mW, 470 Ohms - 150 mW, 600 Ohms - 117 mW
Specifications
This product is in the Hi-Fi and High End Electronics and Acoustics database
Headphones amplifiers — Aune S17 Pro EVO
Model name
S17 Pro EVO
Maximum Power, 32 Ohms (mW RMS per channel)
2050
Maximum Power, 50 Ohms (mW RMS per channel)
N/A
Maximum Power, 300 Ohms (mW RMS per channel)
235
Maximum Power, 600 Ohms (mW RMS per channel)
117
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
80000
Gain (dBu)
N/A
THD (% at 1V RMS, 300 ohms)
0.0003
Signal to Noise Ratio (dB)
115
IMD (%, CCIR, 300 Ohms)
N/A
Crosstalk (dB, 20Hz-20KHz, 300 Ohms)
N/A
Output Impedance (Ohms)
200
Dimensions (mm)
N/A
Weight (g)
N/A
Official link
