CD / SACD players and transports — Luxman D-03R

Description, images, technical data and specifications

Luxman D-03R
Image source — © Luxman

A new CD player with a dedicated digital-to-analog converter functionality, Luxman D-03R replaces the D-03X model. The device's DAC is based on ROHM DB34352EKV chips in a dual mono configuration. The player is reportedly capable of performing USB DAC functions, working with PCM signals up to 32 bit / 384 kHz and DSD up to 22.5 MHz. The MQA format is supported, including MQA-CD.

Specifications

  • Model name

    D-03R

  • Transport

    Yes

  • Player

    Yes

  • SACD support

    N/A

  • Engine

    BD34352EKV ROHM x 2

  • Frequency response low +/- 3dB (for CD) (Hz)

    5

  • Frequency response high +/- 3dB (for CD) (Hz)

    20000

  • Frequency response low +/- 3dB (for SACD) (Hz)

    N/A

  • Frequency response high +/- 3dB (for SACD) (Hz)

    N/A

  • Gain (dBu)

    N/A

  • Output Level (balanced) (V)

    2.4

  • Output Level (single-ended) (V)

    2.4

  • Input Impedance (balanced) (Ω)

    N/A

  • Input Impedance (single-ended) (Ω)

    N/A

  • Output Impedance (balanced) (Ω)

    600

  • Output Impedance (single-ended) (Ω)

    300

  • Dynamic range (for CD) (dB)

    N/A

  • Dynamic range (for SACD) (dB)

    N/A

  • Signal to Noise Ratio (for CD) (dB)

    110

  • Signal to Noise Ratio (for SACD) (dB)

    N/A

  • Total Harmonic Distortion + Noise (for CD) (%)

    0.002

  • Total Harmonic Distortion + Noise (for SACD) (%)

    N/A

  • Dimensions (mm)

    440 x 133 x 410

  • Weight (kg)

    13.2

  • Official link

    https://www.luxman.co.jp/product/d-03r
